Specifications
Please note - specifications subject to change without prior notice.
| FRAME | eBIG.NINE LITE III; MAT aluminium; 29x2.35" without fender max./ 29"x2.25" with fender max. WHS; 148x12 AST; intube |
| SHOCK | |
| FORK | Suntour XCM34-Boost LOR DS; 100mm; Tapered; 51mm fork offset; 29x2.4" max WHS |
| BRAKE-F | Shimano MT-200; 2 piston |
| BRAKE-R | Shimano MT-200; 2 piston |
| ROTOR-FRONT | Shimano RT30; 180 mm |
| ROTOR-REAR | Shimano RTEM300; 180 mm |
| CHAIN | Shimano LG500 |
| CHAINGUARD | |
| CRANKSET | Shimano CRE70-B; 34 ATC |
| CRANK SIZE | Shimano FC-EM600; 165 mm for all sizes |
| DERAILLEUR-FRONT | |
| DERAILLEUR-REAR | Shimano CUES U6000; GS |
| FREEWHEEL | Shimano LG300; 11-48 ATC; 10 GER |
| PEDAL | VP VPE-537 |
| GRIP | MERIDA EXPERT TK |
| HANDLEBAR | MERIDA EXPERT CC; MAT aluminium; 720 WHB; 10 RHB |
| STEM | MERIDA EXPERT CT; MAT aluminium; 31.8 DSH; adjustable |
| STEM SIZE | 90 mm all sizes |
| HEADSET | MERIDA-8155 (for the steerer 1-1/8"~1.5") |
| HUB-F | Shimano TC500-B; 110x15 WHF; 32 SPH; Centerlock |
| HUB-R | Shimano TC500-HM-B; 148x12 WHR; 36 SPH; Centerlock |
| AXLE-F | |
| AXLE-R | MERIDA COMP TR; including removeable lever, 6/4mm allen key |
| SADDLE | MERIDA EXPERT TK; V-mount |
| SEAT CLAMP | MERIDA EXPERT 38.9mm |
| SEAT POST | MERIDA EXPERT CC; MAT aluminium; 34.9 DSP; 0 SSB |
| SHIFTER-F | |
| SHIFTER-R | Shimano CUES U6000-11 |
| SPOKE | Black stainless |
| TIRE-F | KENDA Booster; 29x2.2"; wire |
| TIRE-R | KENDA Booster; 29x2.2"; wire |
| CARRIER | MERIDA MA008-1 w/spring clamp Spanninga GLOW XE |
| FENDER | Sunnywheel SW-FA311-65A/ SW-FA311-65E1 |
| KICKSTAND | CL-KA98, 29" |
| LIGHT-FRONT | LEZYNE E-BIKE HECTO STVZO E65 |
| LIGHT-REAR | Spanninga Commuter GLOW XE |
| FRAME LOCK | Abus 4650 L |
| DRIVE UNIT | Shimano EP6; 85Nm |
| DRIVE COVER | SM-DC-EP801 |
| BATTERY | Shimano EN806; 630Wh |
| SWITCH | |
| DISPLAY | Shimano SC-EN500A |
